SRR6040A-560M Real Image
Same model may have multiple batches, images only for reference.

SRR6040A-560M

Part No SRR6040A-560M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRR6040A-560M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRR6040A
Package Tape & Reel
Material - Core Ferrite
Inductance 56 µH
Tolerance ±20%
Current Rating (Amps) 860 mA
Current - Saturation (Isat) 770mA
Shielding Shielded
DC Resistance (DCR) 190mOhm Max
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 10 kHz
Mounting SMD (SMT)
Package / Case Nonstandard, Corner Terminals
Dimension 0.264" L x 0.264" W (6.70mm x 6.70mm)
Height - Seated (Max) 0.157" (4.00mm)
Base Product Number SRR6040A
Other Names SRR6040A-560MCT,SRR6040A-560MTR,SRR6040A-560MDKR
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273214-SRR6040A-560M
Ultra Librarian 3D Model Ultra Librarian SRR6040A-560M CAD Model

Description

The Bourns Inc. SRR6040A-560M is a shielded fixed inductor with an inductance of 56 µH and a tolerance of ±20%.

  • Application: Automotive
  • Ratings: AEC-Q200
  • DC Resistance (DCR): 190mOhm Max
  • Current Rating: 860 mA
  • Package: Nonstandard, corner terminals
  • Temperature Range: -40°C to 125°C
  • Dimension: 0.264" L x 0.264" W (6.70mm x 6.70mm)
  • Mounted: SMD (SMT) technology
  • Current Saturation (Isat): 770mA
