Same model may have multiple batches, images only for reference.
SRR1280-4R5Y Real Image
Same model may have multiple batches, images only for reference.

SRR1280-4R5Y

Part No SRR1280-4R5Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRR1280-4R5Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRR1280
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 4.5 µH
Tolerance ±30%
Current Rating (Amps) 8.5 A
Current - Saturation (Isat) 9A
Shielding Shielded
DC Resistance (DCR) 13.5mOhm Max
Q @ Freq 20 @ 7.96MHz
Frequency - Self Resonant 34MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height - Seated (Max) 0.315" (8.00mm)
Base Product Number SRR1280
Other Names SRR1280-4R5Y,SRR1280-4R5YCT,SRR1280-4R5YTR,SRR1280-4R5YDKR
Standard Package 400
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273398-SRR1280-4R5Y
Ultra Librarian 3D Model Ultra Librarian SRR1280-4R5Y CAD Model

Description

The Bourns Inc. SRR1280 series inductor is a shielded drum core, wirewound inductor with a 4.5 µH inductance and a ±30% tolerance.

  • DC Resistance: 13.5mOhm max
  • Current Rating: 8.5A
  • Mounting: Surface mount device (SMD) tape and reel package
  • Operating Temperature: -40°C to 125°C
  • Family Name: SRR1280
  • Category: Inductors, coils, and chokes
  • ECCN: EAR99
  • REACH: Unaffected
  • HTSUS Code: 8504.50.4000
