Same model may have multiple batches, images only for reference.

SRP3012TA-8R2M

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SRP3012TA-8R2M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SRP3012TA-8R2M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRP3012TA
Package	Tape & Reel
Type	Drum Core, Wirewound
Material - Core	Carbonyl Powder
Inductance	8.2 µH
Tolerance	±20%
Current Rating (Amps)	1.2 A
Current - Saturation (Isat)	1.7A
Shielding	Shielded
DC Resistance (DCR)	463mOhm Max
Frequency - Self Resonant	26MHz
Ratings	AEC-Q200
Temperature Range - Operating	-40°C ~ 150°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	2-SMD
Supplier Device Package	2-SMD
Dimension	0.138" L x 0.126" W (3.50mm x 3.20mm)
Height - Seated (Max)	0.047" (1.20mm)
Base Product Number	SRP3012TA
Other Names	SRP3012TA-8R2MDKR,SRP3012TA-8R2MTR,SRP3012TA-8R2MCT
Standard Package	4,000
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	1273967-SRP3012TA-8R2M
Ultra Librarian 3D Model	Ultra Librarian SRP3012TA-8R2M CAD Model

Alternative Products

Description

The SRP3012TA-8R2M is a fixed inductor manufactured by Bourns Inc.

Series: SRP3012TA
Type: Drum Core Wirewound
Shielded: Yes
Inductance: 8.2 μH
Tolerance: ±20%
DC Resistance: 463mOhm Max
Height: 0.047" (1.20mm)
Dimension: 0.138" L x 0.126" W (3.50mm x 3.20mm)
Package/Case: 2-SMD
Mounting Type: SMD (SMT)
Rating: AEC-Q200 rated applications
