Same model may have multiple batches, images only for reference.

SRP3012C-R68M

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SRP3012C-R68M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SRP3012C-R68M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRP3012C
Package	Tape & Reel
Material - Core	Metal
Inductance	680 nH
Tolerance	±20%
Current Rating (Amps)	4.5 A
Current - Saturation (Isat)	5.8A
Shielding	Shielded
DC Resistance (DCR)	40mOhm Max
Q @ Freq	10 @ 100kHz
Frequency - Self Resonant	75MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.138" L x 0.126" W (3.50mm x 3.20mm)
Height - Seated (Max)	0.047" (1.20mm)
Other Names	118-SRP3012C-R68MCT,118-SRP3012C-R68MTR,118-SRP3012C-R68MDKR
Standard Package	4,000
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Win Source Part Number	1273979-SRP3012C-R68M
Ultra Librarian 3D Model	Ultra Librarian SRP3012C-R68M CAD Model

Alternative Products

Description

The Bourns SRP3012C-R68M inductor is a shielded, nonstandard package component that has an inductance of 680 nH and a tolerance of ±20%.

Core Material: Metal
Q @ Freq: 10 @ 100kHz
Frequency Self-Resonates: 75MHz
DC Resistance (DCR): 40mOhm Max
Current Rating: 4.5 A
Inductance Frequency-Test: 100 kHz
Temperature Range: -40°C to 125°C
Standard Package: 4,000
Also Known As: 118-SRP3012C-R68MCT, 118-SRP3012C-R68MTR, and 118-SRP3012C-R68MDKR
