Same model may have multiple batches, images only for reference.
SRP0615-2R2K Real Image
Same model may have multiple batches, images only for reference.

SRP0615-2R2K

Part No SRP0615-2R2K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP0615
Package Tape & Reel
Material - Core Metal
Inductance 2.2 µH
Tolerance ±10%
Current Rating (Amps) 6 A
Current - Saturation (Isat) 9.4A
Shielding Shielded
DC Resistance (DCR) 33.5mOhm Max
Q @ Freq 47 @ 7.96MHz
Frequency - Self Resonant 25MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.280" L x 0.264" W (7.10mm x 6.70mm)
Height - Seated (Max) 0.059" (1.50mm)
Other Names 118-SRP0615-2R2KDKR,118-SRP0615-2R2KTR,118-SRP0615-2R2KCT
Standard Package 2,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274170-SRP0615-2R2K
Ultra Librarian 3D Model Ultra Librarian SRP0615-2R2K CAD Model

Description

The Bourns Inc. SRP0615-2R2K is a fixed inductor with a shielded feature.

  • Tolerance: ±10%
  • Mounting: SMD (SMT)
  • Core Material: Metal
  • Q @ Freq: 47 @ 7.96MHz
  • Frequency Self-Resonant: 25MHz
  • DC Resistance (DCR): 33.5mOhm Max
  • Current Rating (Amps): 6A
  • Operating Temperature: -40°C to 125°C
  • Package/Case: Nonstandard
