SRE6603-4R7M Real Image
Same model may have multiple batches, images only for reference.

SRE6603-4R7M

Part No SRE6603-4R7M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRE6603-4R7M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRE6603
Package Tape & Reel (TR)
Product Status Obsolete
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 4.7 µH
Tolerance ±20%
Current Rating (Amps) 1.4 A
Current - Saturation (Isat) 580mA
Shielding Shielded
DC Resistance (DCR) 60mOhm Max
Q @ Freq 40 @ 200kHz
Frequency - Self Resonant 105MHz
Temperature Range - Operating -25°C ~ 105°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) 0.115" (2.92mm)
Base Product Number SRE6603
Standard Package 2,000
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274455-SRE6603-4R7M
Ultra Librarian 3D Model Ultra Librarian SRE6603-4R7M CAD Model

Description

The SRE6603 series from Bourns Inc. is a fixed inductor designed for use in various applications.

  • Model: SRE6603-4R7M
  • Core: drum core, wirewound type
  • Shielding: Yes
  • Inductance: 4.7 µH
  • Tolerance: ±20%
  • Q @ Freq: 40 @ 200kHz
  • Self-Resonant Frequency: 105MHz
  • DC Resistance (DCR): 60mOhm max
  • Package/Case: nonstandard
  • Packaging: tape & reel (TR)
  • Standard Package: 2,000
  • Temperature Range: -25°C to 105°C
  • Current Rating: 1.4 A
