SDE0805A-470K Real Image
Same model may have multiple batches, images only for reference.

SDE0805A-470K

Part No SDE0805A-470K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SDE0805A-470K Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SDE0805A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 47 µH
Tolerance ±10%
Current Rating (Amps) 1.7 A
Current - Saturation (Isat) 1.4A
Shielding Unshielded
DC Resistance (DCR) 180mOhm Max
Frequency - Self Resonant 12.1MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 MHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Max) 0.217" (5.50mm)
Base Product Number SDE0805A
Other Names SDE0805A-470KDKR,SDE0805A-470KTR,SDE0805A-470KCT
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274895-SDE0805A-470K
Ultra Librarian 3D Model Ultra Librarian SDE0805A-470K CAD Model

Description

The SDE0805A-470K is a fixed inductor from Bourns Inc.

  • Core Type: Drum Core
  • Inductor Type: Wirewound
  • Shielding: Unshielded
  • Inductance: 47 µH
  • Tolerance: ±10%
  • Core Material: Ferrite
  • DC Resistance (DCR): 180mOhm maximum
  • Temperature Range: -40°C to 125°C
  • Packaging: Tape and Reel
  • Package/Case: Nonstandard
  • Mounting Type: Surface-Mount Technology (SMT)
  • Series: SDE0805A
  • Rating: AEC-Q200
