8114-RC Bourns Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

8114-RC

Part No 8114-RC
Manufacturer Bourns Inc.
Catalog Common Mode Chokes
Description CMC 2.5MH 12.5A 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Lines 2
Inductance @ Frequency 2.5 mH @ 1 kHz
Current Rating (Max) 12.5A
DC Resistance (DCR) (Max) 11mOhm
Temperature Range - Operating -55°C ~ 105°C
Mounting Type Through Hole
Size / Dimension 1.450" L x 0.800" W (36.83mm x 20.32mm)
Height (Max) 1.500" (38.10mm)
Case / Package Vertical, 4 PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1530330-8114-RC
Ultra Librarian 3D Model Ultra Librarian 8114-RC CAD Model

Description

N
