Same model may have multiple batches, images only for reference.

DFA20E24S15

Name: DFA20E24S15
Brand: Bel Power Solutions
SKU: 584520
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	DFA20E24S15
Manufacturer	Bel Power Solutions
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 15V 20W
Datasheet	DFA20E24S15 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	Bel Power Solutions
Series	DFA20
Package	Bulk
Product Status	Obsolete
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	18V
Voltage - Input (Max)	36V
Voltage - Output 1	15V
Current - Output (Max)	1.4A
Power (Watts)	20 W
Voltage - Isolation	700 V
Applications	ITE (Commercial)
Temperature Range - Operating	-50°C ~ 100°C
Efficiency	86%
Mounting Type	Through Hole
Package / Case	7-DIP Module
Size / Dimension	2.02" L x 2.02" W x 0.45" H (51.3mm x 51.3mm x 11.4mm)
Standard Package	125 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	584520-DFA20E24S15
Ultra Librarian 3D Model	Ultra Librarian DFA20E24S15 CAD Model

Alternative Products

Description

The DFA20E24S15 is a high-quality DC-DC converter module from Bel Power Solutions.

Series: DFA20
Power Output: 20W
Module Type: Isolated
Application: Commercial IT Equipment
Size: 2.02" L x 2.02" W x 0.45" H
Output Voltage: 15V
Output Current: 1.4A (Maximum)
Input Voltage Range: 18V to 36V
Efficiency: 86%
Mounting Type: Through-Hole
Package: Bulk (125 pieces)
