20IMX4-2424-8G

Part No 20IMX4-2424-8G
Manufacturer Bel Power Solutions
Catalog DC DC Converters
Description DC DC CONVERTER +/-24V 3.8W
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Isolated Module, Conformal Coated
Number of Outputs 2
Voltage - Input (Min) 8.4V
Voltage - Input (Max) 36V
Voltage - Output 1 24V
Voltage - Output 2 -24V
Current - Output (Max) 80mA, 80mA
Power (Watts) 3.8 W
Voltage - Isolation 2 kV
Applications ITE (Commercial), Railway
Features OCP, OTP, OVP, SCP
Temperature Range - Operating -40°C ~ 85°C
Efficiency 83%
Mounting Type Through Hole
Case / Package 24-DIP Module, 13 Leads
Size / Dimension 1.30" L x 0.79" W x 0.33" H (33.0mm x 20.1mm x 8.4mm)
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1537156-20IMX4-2424-8G
Ultra Librarian 3D Model Ultra Librarian 20IMX4-2424-8G CAD Model
