0685-4000-S1 Real Image
Same model may have multiple batches, images only for reference.

0685-4000-S1

Part No 0685-4000-S1
Manufacturer Bel Fuse Inc.
Catalog Fuses
Description FUSE BOARD MNT 4A 63VAC/VDC 1206
Datasheet
0685-4000-S1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Bel Fuse Inc.
Packaging Reel - TR
Status Active
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating 4A
Voltage Rating - AC 63V
Voltage Rating - DC 63V
Response Time Slow
Mounting SMD (SMT)
Breaking Capacity @ Rated Voltage 50A
Nominal Melting - I2t 2.05
Approvals CE, cURus
Temperature Range - Operating -55°C to 125°C
Nominal Cold Resistance 0.032 Ohm
Win Source Part Number 197157-0685-4000-S1
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 0685-4000-S1 CAD Model

Description

Product Overview

The 0685-4000-S1 component is engineered for demanding environments, offering top-notch efficiency and reliability. Its versatile design is suited for both new installations and upgrades.

Features and Benefits

  • Advanced circuit protection
  • Space-saving design
  • Cost-effective solution with high reliability

Applications and Projects

  • Renewable energy systems
  • Telecommunication equipment
  • Robotics
  • Building management systems

The 0685-4000-S1 provides a balance of performance and economy, ensuring value in a wide array of applications.
