The TAJC106K016RNJ is a tantalum capacitor manufactured by AVX Corporation. It belongs to the TAJ series, known for their reliability and performance in general-purpose applications. This component is a surface mount device (SMD), making it suitable for automated assembly processes and high-density circuit board designs. The 'RNJ' suffix often indicates specific packaging or termination options.

Applications

• Power supply decoupling
• Bypass capacitors in electronic circuits
• DC-DC converters
• Portable electronic devices (smartphones, tablets)
• Industrial control equipment

Features

• Surface Mount Technology (SMT)
• Solid tantalum capacitor
• Molded case for protection and dimensional stability
• Stable electrical characteristics over temperature
• RoHS compliant

Benefits

• Compact size reduces board space requirements
• Suitable for automated assembly processes
• Reliable performance in demanding environments
• Consistent electrical performance
• Environmentally responsible

Specifications

The TAJC106K016RNJ features a capacitance of 10µF with a tolerance of ±10%. Its rated voltage is 16VDC. The operating temperature range is typically -55°C to +125°C. The case size is C case. The Equivalent Series Resistance (ESR) is a key parameter for high-frequency applications and is detailed in the AVX datasheet. The terminations are typically tin-plated for easy soldering. Voltage derating is recommended for long-term reliability.

For complete and accurate specifications, including ESR values, ripple current ratings, and soldering profiles, refer to the official AVX datasheet. Proper application of this capacitor requires attention to these details to ensure optimal performance and lifespan.
