Same model may have multiple batches, images only for reference.
CB037D0224JBA Real Image
Same model may have multiple batches, images only for reference.

CB037D0224JBA

Part No CB037D0224JBA
Manufacturer AVX Corporation
Catalog Film Capacitors
Description CAP FILM 0.22UF 5% 63VDC 1812
Datasheet
CB037D0224JBA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Capacitors
Estimated Pruduction Lead Time 13 Weeks
Features 0.22 µF Film Capacitor 40V 63V Polyester, Polyethylene Naphthalate (PEN), Metallized - Stacked 1812 (4532 Metric)
Manufacturer AVX Corporation
Series CB
Package Reel - TR
Operating Temperature Range -55°C ~ 125°C
Mounting Surface Mount
Package 1812 (4532 Metric)
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.25.0010
Other Part Number 478-6004-2, 478-6004-1, 478-6004-6
Quantity per package 700
Popularity High
Supply and Demand Status Balance
Win Source Part Number 914789-CB037D0224JBA
Ultra Librarian 3D Model Ultra Librarian CB037D0224JBA CAD Model

Description

The CB037D0224JBA is a film capacitor manufactured by AVX Corporation.

  • Capacitance: 0.22uF
  • Voltage Rating: 40V
  • Temperature Range: -55°C to 125°C
  • Package: Surface Mount
  • Configuration: Stacked 1812 (4532 Metric)
  • Popularity: High popularity
  • Supply and Demand Status: Balanced
