The SR215C224MAATR1 is a ceramic multilayer capacitor (MLCC) produced by AVX Corp/Kyocera Corp. It's designed for surface mounting (SMD) and provides a reliable, stable capacitance for a variety of electronic applications. Its construction allows for efficient performance in demanding conditions.

Applications

• Decoupling in power supplies
• Bypass capacitors in digital circuits
• Filtering in analog circuits
• Timing circuits
• General-purpose applications requiring stable capacitance

Features

• Capacitance: 0.22µF (220nF)
• Voltage Rating: 50V
• Dielectric Material: X7R
• Case Size: 2220 (EIA)
• Termination: Surface Mount (SMD)
• RoHS Compliant

Benefits

• Stable capacitance over temperature variations (X7R dielectric)
• Effective decoupling and filtering in various electronic circuits
• Easy assembly with surface mount technology
• Space-saving design due to the 2220 case size
• Reliable performance in harsh environmental conditions
• Environmentally friendly due to RoHS compliance

Additional Details

The X7R dielectric ensures that the SR215C224MAATR1 maintains a consistent capacitance value even when subjected to temperature changes. Specifically, X7R dielectric materials typically exhibit a capacitance variation of ±15% over a temperature range of -55°C to +125°C. The 2220 case size denotes the physical dimensions, roughly 0.22 inches in length and 0.20 inches in width, allowing for high-density board layouts. The capacitor's low Equivalent Series Resistance (ESR) contributes to its efficiency in high-frequency applications. The SR215C224MAATR1 is commonly used in power supplies, consumer electronics, and industrial applications where stable capacitance and reliable performance are critical. The tape and reel packaging is designed for high-speed automated assembly, reducing manufacturing costs. Its non-polar nature simplifies circuit design as there is no polarity constraint when mounting the component.
