The HSMS-282C is a surface mount Schottky diode from AVAGO TECHNOLOGIES LIMITED. This diode is designed for high-performance mixer and detector applications in the microwave and millimeter-wave frequency ranges. Its low series resistance and small junction capacitance make it an excellent choice for demanding RF and microwave circuits.

Applications

• RF Mixers: Used in frequency mixers to convert signals to different frequencies.
• Detectors: Employed in detectors to convert RF signals to DC voltages.
• Sampling circuits: Suitable for high-speed sampling applications.
• Frequency Doublers: Used in circuits that double the frequency of an input signal.
• RF Switches: Incorporated into RF switches for high-speed signal control.

Features

• Low series resistance: Minimizes signal loss and improves performance.
• Small junction capacitance: Enables high-frequency operation and reduces parasitic effects.
• Surface mount package: Allows for automated assembly and compact design.
• High breakdown voltage: Provides robustness and reliability in high-voltage applications.
• Fast switching speed: Enables rapid signal processing.
• RoHS compliant: Environmentally friendly and compliant with regulations.

Benefits

• Improved sensitivity: Enhances the ability to detect weak signals.
• Increased efficiency: Reduces power consumption and improves overall system performance.
• Compact design: Enables miniaturization of RF and microwave circuits.
• High reliability: Ensures consistent performance and long lifespan.
• Simplified assembly: Facilitates automated manufacturing processes.

Additional Details

The HSMS-282C typically features a forward voltage of around 0.35V and a reverse breakdown voltage of over 15V. Its operating frequency range extends into the GHz region, making it suitable for a wide array of wireless communication and radar systems. The diode is available in various surface mount packages, such as SOT-23 and SOD-323, providing flexibility in circuit board layout. It is commonly used in applications requiring high sensitivity, low noise, and fast switching speeds. The HSMS-282C is manufactured using advanced semiconductor processing techniques to ensure consistent performance and high reliability. The diode's performance characteristics are typically specified at various frequencies and temperatures to facilitate accurate circuit design and optimization.
