Same model may have multiple batches, images only for reference.

CXA20-48S05J

Name: CXA20-48S05J
Brand: Artesyn Embedded Technologies
SKU: 581107
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	CXA20-48S05J
Manufacturer	Artesyn Embedded Technologies
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 5V 20W / Isolated Module DC DC Converter 1 Output 5V 4A 18V - 75V Input
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	Artesyn Embedded Technologies
Series	CXA20 (20W)
Package	Bulk
Product Status	Obsolete
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	18V
Voltage - Input (Max)	75V
Voltage - Output 1	5V
Current - Output (Max)	4A
Power (Watts)	20 W
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	Remote On/Off, OCP, OTP, OVP, SCP, UVLO
Temperature Range - Operating	-40°C ~ 60°C
Efficiency	83%
Mounting Type	Through Hole
Package / Case	8-DIP Module, 6 Leads
Size / Dimension	2.00" L x 1.60" W x 0.41" H (50.8mm x 40.6mm x 10.5mm)
Standard Package	50 pcs
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	581107-CXA20-48S05J
Ultra Librarian 3D Model	Ultra Librarian CXA20-48S05J CAD Model

Alternative Products

Description

The CXA20-48S05J is a 20W isolated module power supply designed for board mount applications.

Series: CXA20
Power Output: 20W
Size: 2.00" L x 1.60" W x 0.41" H (50.8mm x 40.6mm x 10.5mm)
Outputs: Single
Maximum Current: 4A
Input Voltage Range: 18V to 75V
Output Voltage: Fixed @ 5V
Protection: Remote on/off, OCP, OTP, OVP, SCP, and UVLO
Efficiency: 83%
Temperature Range: -40°C to 60°C
Applications: ITE (Commercial)
Mounting Type: Through-hole
