ASA01F18-L Astec America, Inc
Same model may have multiple batches, images only for reference.

ASA01F18-L

Part No ASA01F18-L
Manufacturer Artesyn Embedded Technologies
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 3.3V 6W
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Artesyn Embedded Technologies
Series ASA (6W)
Package Tube
Product Status Obsolete
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 9V
Voltage - Input (Max) 36V
Voltage - Output 1 3.3V
Current - Output (Max) 1.2A
Power (Watts) 6 W
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features SCP
Temperature Range - Operating -40°C ~ 71°C
Efficiency 81%
Mounting Type Through Hole
Package / Case 8-DIP Module
Size / Dimension 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
Standard Package 200 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 564915-ASA01F18-L
Ultra Librarian 3D Model Ultra Librarian ASA01F18-L CAD Model

Description

The ASA (6W) series DC-DC converter, part number 564915-ASA01F18-L, is a compact and efficient power supply solution for various electronic applications.

  • Power Output: 6W
  • Output Voltage: 3.3V
  • Type: isolated module converter
  • Protection: short circuit protection (SCP)
  • Input Voltage Range: 9V to 36V
  • Efficiency: 81%
  • Mounting: through-hole
  • Size: 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
  • Applications: ITE (Commercial)
  • Standard Package: 200 pcs
  • Manufacturer: Artesyn Embedded Technologies
