Same model may have multiple batches, images only for reference.

ASA00AA18-L

Name: ASA00AA18-L
Brand: Artesyn Embedded Technologies
SKU: 564908
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	ASA00AA18-L
Manufacturer	Artesyn Embedded Technologies
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER +/-5V 6W
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	Artesyn Embedded Technologies
Series	ASA (6W)
Package	Tube
Product Status	Obsolete
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Min)	9V
Voltage - Input (Max)	36V
Voltage - Output 1	5V
Voltage - Output 2	-5V
Current - Output (Max)	500mA, 500mA
Power (Watts)	6 W
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	SCP
Temperature Range - Operating	-40°C ~ 71°C
Efficiency	81%
Mounting Type	Through Hole
Package / Case	8-DIP Module
Size / Dimension	1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
Standard Package	200 pcs
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	564908-ASA00AA18-L
Ultra Librarian 3D Model	Ultra Librarian ASA00AA18-L CAD Model

Alternative Products

Description

The ASA00AA18-L is a 6W isolated module power supply from Artesyn Embedded Technologies.

Category: Power supplies - board mount - DC DC converters
Features: Short circuit protection (SCP)
Package: Tube
Dimensions: 1.25" L x 0.80" W x 0.40" H
Application: ITE (commercial)
Standard Package: 200 pcs
Power Output: 6W
Isolation Voltage: 1.5 kV
Outputs: Two
Maximum Currents: 500mA each
Input Voltage Range: 9V to 36V
Output Voltages: 5V and -5V
Efficiency: 81%
Mounting: Through-hole
Operating Temperature Range: -40°C to 71°C
Status: Obsolete
ECCN: EAR99
