AEH20A48 Real Image
Same model may have multiple batches, images only for reference.

AEH20A48

Part No AEH20A48
Manufacturer Artesyn Embedded Technologies
Catalog Power Supplies Board Mount DCDC Converters
Description 50-150 Watts | DC DC CONVERTER 5V 100W
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer Artesyn Embedded Technologies
Packaging Bulk
Status Obsolete
Type Non-Isolated PoL Module
Voltage - Input (Minimum) 36V
Voltage - Input (Maximum) 72V
Voltage - Output 1 5V
Current - Output (Maximum) 20A
Power (W) 100W
Applications ITE (Commercial)
Features Remote On/Off
Temperature Range - Operating -40°C ~ 100°C
Efficiency 90%
Mounting Style Through Hole
Manufacturer Package 9-DIP Module
Parts Dimension 2.40" L x 2.30" W x 0.50" H (61.0mm x 58.4mm x 12.7mm)
Control Features Enable, Active High
Manufacturer Pack Quantity 10
MSL Level 1 (Unlimited)
Win Source Part Number 1142805-AEH20A48
Manufacturer Homepage www.astecinc.com/
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian AEH20A48 CAD Model

Description

Artesyn Embedded Technologies introduces AEH20A48, a non-isolated PoL module DC DC converter.

  • Remote On/Off: Yes
  • Manufacturer Package: 9-DIP module
  • Power Output: 100W
  • Input Voltage Range: 36V to 72V
  • Voltage Output: 5V
  • Efficiency: 90%
  • Mounting Style: Through-hole
  • Operating Temperature: -40°C ~ 100°C
  • Category: Power Supplies - Board Mount
  • Popularity: Medium
  • Supply and Demand: Limited
  • MSL Level: 1 (Unlimited)
  • HTSUS: 8504.40.9580
