The Anaren XC0900P-10SR is a high-performance, low-profile Xinger® brand 900 MHz coupler designed for various wireless communication applications. This coupler offers excellent insertion loss, high isolation, and tight coupling, making it suitable for power amplifiers, antenna feeds, and signal distribution networks operating in the 860-960 MHz frequency range.

Applications

• Wireless Communication Systems: Used in base stations and repeater systems operating in the 900 MHz ISM band.
• Power Amplifiers: Implemented in power amplifier designs for impedance matching and signal combining.
• Antenna Feeds: Employed in antenna feed networks for signal splitting and combining to optimize antenna performance.
• Signal Distribution Networks: Utilized in distributing RF signals across various paths in a system while maintaining signal integrity.
• ISM Band Applications: Specifically designed for applications operating in the 860-960 MHz Industrial, Scientific, and Medical (ISM) frequency band.

Features

• High Isolation: Provides high isolation between the coupled and isolated ports, minimizing unwanted signal leakage.
• Low Insertion Loss: Minimizes signal attenuation, ensuring efficient power transfer.
• Tight Coupling: Offers precise coupling values for accurate signal splitting and combining.
• Surface Mount Package: Designed for easy and reliable surface mount assembly.
• Xinger® Brand Quality: Built with Anaren's renowned Xinger® brand quality, ensuring high performance and reliability.

Benefits

• Improved System Performance: Enhances overall system performance by minimizing signal loss and maximizing signal isolation.
• Simplified Circuit Design: Simplifies circuit design with its compact size and easy integration.
• Increased Reliability: Offers high reliability due to its robust design and high-quality materials.
• Reduced Signal Interference: Minimizes signal interference, ensuring clean and accurate signal transmission.
• Optimized Power Transfer: Facilitates efficient power transfer, improving overall system efficiency.

Additional Details

The XC0900P-10SR is a 3 dB hybrid coupler. It comes in a surface mount package compatible with automated assembly processes. This coupler is designed to handle moderate power levels typical of wireless communication systems. The small form factor makes it suitable for compact PCB designs. It meets RoHS compliance standards, ensuring environmental safety.
