The SSM2356CBZ-RL7 is a cutting-edge, fully integrated, high-efficiency, Class-D audio amplifier designed and manufactured by Analog Devices Inc. This powerful audio solution is tailored for a wide range of applications where high-quality sound reproduction is essential, including portable and consumer audio systems, televisions, computers, and multimedia speakers.

Key Features

• High Efficiency: The Class-D architecture provides an efficient solution for audio amplification, minimizing heat generation and power loss, thus extending battery life in portable applications.
• Output Power: Capable of delivering 2.5W into a 4Ω load, the SSM2356CBZ-RL7 ensures robust audio performance with minimal distortion.
• Single-Supply Operation: Designed to operate on a single supply voltage ranging from 2.5V to 5.5V, this amplifier offers flexibility and convenience in various system designs.
• Filterless Design: The SSM2356CBZ-RL7 does not require an external output filter, reducing component count and simplifying the design process.
• Integrated Protection: Features such as over-temperature protection, output short-circuit protection, and under-voltage lockout ensure reliable operation and safeguard the device from potential damage.
• Pop & Click Suppression: The built-in pop and click suppression circuitry ensures smooth start-up and shutdown transitions, preventing any unwanted noise.

Applications

• Portable Audio Devices
• Consumer Audio Systems
• Television Sound Systems
• Computer and Multimedia Speakers
• Mobile Phones and Tablets

Package and Availability

The SSM2356CBZ-RL7 is offered in a compact 9-ball, 1.5mm x 1.5mm WLCSP (Wafer Level Chip Scale Package) that is ideal for space-constrained applications. This product is available in reel form, facilitating efficient integration into automated manufacturing processes.

Analog Devices Inc. is renowned for its commitment to high-quality products, and the SSM2356CBZ-RL7 is no exception. With its superior sound quality, efficiency, and ease of integration, this audio amplifier stands out as a top choice for designers seeking a reliable and high-performance audio amplification solution.
