Product Overview

Introducing the REF196GSZ-REEL7, a precision voltage reference component from the reputable manufacturer Analog Devices Inc. This high-quality product is designed to offer a stable and precise reference voltage, which is crucial for the accurate operation of analog-to-digital converters, digital-to-analog converters, and other sensitive electronic circuits.

Key Features

• Output Voltage: The REF196GSZ-REEL7 provides a fixed output voltage of 5V, making it versatile for a wide range of applications that require a standard reference voltage.
• Low Temperature Coefficient: With a low temperature coefficient, this voltage reference maintains consistent performance across a broad temperature range, ensuring reliability in varying environmental conditions.
• High Accuracy: The component is characterized by its high accuracy, minimizing errors in the systems where it is employed and thus enhancing overall performance.
• Low Dropout Voltage: The REF196GSZ-REEL7 operates efficiently with a low dropout voltage, allowing it to function correctly even when the supply voltage is close to the output voltage.
• Package Type: It comes in an 8-SOIC (0.154", 3.90mm Width) package, which is suitable for surface-mount technology, facilitating easy integration into various electronic systems.
• Supply Voltage Range: This voltage reference can operate over a wide supply voltage range, providing designers with flexibility in system power design.
• Output Current: It is capable of sourcing and sinking output current, making it adaptable for both high-side and low-side reference applications.

Applications

The REF196GSZ-REEL7 is ideal for use in precision data systems, industrial controls, battery-operated devices, and portable medical instruments, where stable and accurate reference voltages are critical for operational integrity.

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality, and the REF196GSZ-REEL7 is no exception. It is manufactured to meet high standards, ensuring that each component delivers consistent performance and reliability. The product is available in a reel packaging format, denoted by the REEL7 suffix, which is convenient for automated assembly processes and large-scale production requirements.

With its robust design and precise voltage output, the REF196GSZ-REEL7 from Analog Devices Inc. is an excellent choice for designers looking for a reliable voltage reference for their electronic projects.
