The REF02H from Analog Devices Inc. is a high-precision voltage reference that provides a fixed 5V output with an impressive ±0.5% initial accuracy. Designed for a wide array of applications, this voltage reference is a staple component in many precision measurement devices, including digital voltmeters, data acquisition systems, and analog-to-digital converters.

Key Features

• Output Voltage: Stable 5V ±0.5% initial accuracy.
• Temperature Coefficient: Low temperature coefficient of 10ppm/°C max for robust performance over a wide temperature range.
• Supply Voltage Range: Operates with a supply voltage range from 7V to 40V, providing versatility in various power supply configurations.
• Load Regulation: Excellent load regulation characteristics ensure consistent performance with varying load conditions.
• Low Quiescent Current: Features a low quiescent current, making it suitable for battery-powered applications.
• Package Options: Available in various packages, including the compact 8-lead SOIC and PDIP, suitable for space-constrained applications.

Applications

The REF02H is ideal for high-precision applications where a stable reference voltage is critical. Its reliability and accuracy make it suitable for:

• Precision data systems
• Industrial instrumentation
• ADCs and DACs
• Battery-powered equipment
• Automotive electronics

Reliability and Support

Analog Devices Inc. is known for its commitment to quality and reliability, and the REF02H is no exception. With its robust design and stringent quality control, customers can rely on this voltage reference for their critical applications. Additionally, comprehensive technical support is available, including datasheets, application notes, and design resources to assist engineers in integrating the REF02H into their designs.
