Product Overview: HMC564LC4TR by Analog Devices Inc.

The HMC564LC4TR is a high-performance, wideband, Double-Balanced Mixer designed by Analog Devices Inc., a leader in the semiconductor industry. This advanced component is part of the Hittite microwave product family and is engineered to meet the demanding requirements of communication, test and measurement, and military applications.

Operating over an RF and LO frequency range of 6 GHz to 26 GHz with an IF frequency range of DC to 8 GHz, the HMC564LC4TR offers exceptional versatility. This mixer provides users with a wide range of potential uses, from satellite communications to radar systems. Its high isolation and low conversion loss make it an ideal choice for complex RF systems.

The HMC564LC4TR is housed in a compact 4x4 mm surface-mount leadless chip carrier package, which allows for efficient use of board space and is compatible with automated assembly equipment. This package is not only space-saving but also offers excellent electrical and thermal performance.

This mixer's design incorporates on-chip balun structures which provide a balanced performance and simplify the RF and LO interfaces. The integrated baluns reduce the need for external components, thus minimizing the overall component count and simplifying the design-in process for engineers.

Key features of the HMC564LC4TR include:

• Wideband performance with RF/LO frequency from 6 GHz to 26 GHz
• IF frequency range from DC to 8 GHz
• Passive double-balanced mixer design
• High isolation and low conversion loss
• Compact 4x4 mm SMT package
• Integrated on-chip balun structures

The combination of wide frequency range, high performance, and compact form factor makes the HMC564LC4TR a superior choice for system designers looking to create high-frequency, high-precision applications. Analog Devices Inc. ensures that this product meets rigorous quality standards, providing reliability and performance that customers expect from a leading semiconductor manufacturer.
