HMC510LP5 Analog Devices Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

HMC510LP5

Part No HMC510LP5
Manufacturer Analog Devices Inc.
Catalog VCOs (Voltage Controlled Oscillators)
Description VCO 4.5GHZ/9GHZ 2-13V 5X5MM
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Frequency Range 4.225 ~ 4.775GHz, 8.45 ~ 9.55GHz
Frequency - Center 4.5GHz, 9GHz
Voltage - Supply 5V
Tuning Voltage (VDC) 2 V ~ 13 V
2nd Harmonic, Typ (dBc) 15
Icc Max 360mA
Pushing (MHz/V) 20
Power (dBm) -6±2, 11±3, 12.5±2.5
Phase Noise Typ (dBc/Hz) -116
Temperature Range - Operating -40°C ~ 85°C
Case / Package 32-VFQFN Exposed Pad
Size / Dimension 0.197" L x 0.197" W (5.00mm x 5.00mm)
Height 0.039\
Package Strip
Supply and Demand Status Shortage
Win Source Part Number 1530050-HMC510LP5
Ultra Librarian 3D Model Ultra Librarian HMC510LP5 CAD Model
