The HMC495LP3ETR from Analog Devices Inc. is a high-performance, passive frequency multiplier that is designed to meet the stringent requirements of RF and microwave communication systems. This device is part of Analog Devices' Hittite Microwave product line and is ideal for applications requiring frequency multiplication with minimal additive phase noise and high signal purity.

Key Features

• Frequency Range: The HMC495LP3ETR operates over a wide frequency range, making it versatile for various applications including point-to-point radios, VSAT, military and space, and test equipment.
• Passive Design: As a passive device, it does not require a DC power supply, which simplifies circuit design and enhances reliability.
• High Isolation: The multiplier provides excellent isolation between input and output, minimizing the potential for feedback that could affect performance.
• Surface-Mount Package: Encased in a compact 3x3 mm QFN package, the HMC495LP3ETR is suitable for surface-mount technology (SMT), allowing for efficient assembly and space-saving on circuit boards.

Performance Specifications

• Output Frequency: The device is capable of generating an output frequency that is a fixed multiple of the input frequency, with low phase noise and spurious products.
• Conversion Loss: It offers a typical conversion loss of 13 dB, providing a balance between signal strength and harmonic suppression.
• Quality Construction: Built with Analog Devices' proven technology, the HMC495LP3ETR ensures consistent performance and durability.

Applications

The HMC495LP3ETR is suitable for a wide array of applications, including but not limited to:

• Fiber optic systems
• Test instrumentation
• Satellite communications
• Military radar systems
• Wireless infrastructure

With its robust design and versatile performance, the HMC495LP3ETR from Analog Devices Inc. is a reliable choice for designers looking to enhance their RF and microwave systems with a high-quality frequency multiplier.
