ADXL330KCPZ-RL1 - Analog Devices Inc.

The ADXL330KCPZ-RL1 is a small, thin, low power, complete 3-axis accelerometer with signal conditioned voltage outputs, all on a single monolithic IC. Manufactured by Analog Devices Inc., a leader in high-performance semiconductors for signal processing applications, this accelerometer is designed to measure acceleration with a full-scale range of ±3 g. It can measure the static acceleration of gravity in tilt-sensing applications, as well as dynamic acceleration resulting from motion, shock, or vibration.

Key Features and Benefits

• 3-axis sensing: Provides simultaneous X, Y, and Z-axis acceleration sensing, allowing for comprehensive tracking of motion and orientation.
• Low power consumption: Ideal for battery-powered applications, the ADXL330KCPZ-RL1 is optimized for low power consumption, extending the life of portable devices.
• High sensitivity: Offers precise, high-resolution acceleration measurement, ensuring accurate data for your application needs.
• Compact form factor: Housed in a small LFCSP (Lead Frame Chip Scale Package), it is suitable for space-constrained applications.
• Wide voltage range: Operates on a 2.0V to 3.6V supply voltage range, providing flexibility in various system designs.

Applications

The ADXL330KCPZ-RL1 is versatile and can be used in a wide array of applications, including:

• Mobile devices (phones, gaming controllers)
• Sports and health devices
• Industrial monitoring and control
• Robotics and UAVs (Unmanned Aerial Vehicles)
• Vehicle dynamics

Technical Specifications

• Sensitivity: Typically 300 mV/g at 3V
• Measurement Range: ±3 g
• Bandwidth: X/Y axes: 1600 Hz, Z axis: 550 Hz
• Temperature Range: -40°C to +85°C
• Package: 16-lead, 4 mm × 4 mm × 1.45 mm LFCSP

The ADXL330KCPZ-RL1 is a robust and reliable solution for applications requiring high-performance motion sensing in a compact package. Analog Devices Inc. ensures that this accelerometer meets the highest standards for quality and performance, making it a preferred choice for engineers and designers across various industries.
