ADUM6401CRWZ-RL Digital Isolator by Analog Devices Inc.

The ADUM6401CRWZ-RL is a state-of-the-art digital isolator designed and manufactured by Analog Devices Inc., a leader in the semiconductor industry. This product is part of the ADuM640x series, which offers quad-channel digital isolation with integrated, isolated DC-to-DC converters. The ADUM6401CRWZ-RL, in particular, is known for its high-performance capabilities in isolating data channels and providing power through its innovative iCoupler® and isoPower® technologies.

This digital isolator features a robust isolation barrier that can withstand up to 2.5kVrms for one minute, ensuring that the data and power domains are kept separate to protect sensitive electronic equipment from high voltage transients. The device operates with an input voltage range of 3.0V to 5.5V, making it versatile for various applications and compatible with many microcontrollers and digital systems.

With a compact 16-lead SOIC-W package, the ADUM6401CRWZ-RL is designed for space-constrained applications without compromising on performance. Its integrated, isolated DC-to-DC converter provides up to 100mW of output power, which is ideal for powering isolated circuits without the need for a separate isolated power supply. The product's four independent isolation channels support data rates up to 10Mbps, providing efficient and reliable communication for industrial, medical, and automotive systems.

Key features of the ADUM6401CRWZ-RL include:

• Quad-channel digital isolation (2/2 channel directionality)
• Integrated, isolated DC-to-DC converter
• High data rate transfer of up to 10Mbps
• Robust 2.5kVrms isolation rating
• Wide input voltage range from 3.0V to 5.5V
• Low power operation and power-saving modes
• 16-lead SOIC-W package for space-saving installation

The ADUM6401CRWZ-RL is a reliable solution for applications requiring data and power isolation to maintain integrity and safety in harsh electrical environments. Its ease of use and integration, combined with the quality assurance of Analog Devices Inc., make it an excellent choice for designers and engineers looking to enhance their systems with isolated data and power channels.
