ADUM6212CRSZ - Isolated DC-to-DC Converter

The ADUM6212CRSZ is a cutting-edge, isolated DC-to-DC converter manufactured by Analog Devices Inc., designed to provide both isolated power and isolated data in a single package. This product is part of the ADuM621x series, which are dual-channel digital isolators with isoPower®, an integrated, isolated dc-to-dc converter. Based on Analog Devices' proprietary iCoupler® technology, the ADUM6212CRSZ offers reliable performance for applications that require electrical isolation between the input and output domains.

With an input voltage range of 3.0 V to 5.5 V, this converter is versatile and can be used in a variety of systems. The output regulated voltage is set at 5.0 V, and the device is capable of delivering up to 150 mW of output power, making it suitable for powering small isolated circuits without the need for an additional isolated power supply.

The ADUM6212CRSZ comes in a compact, 16-lead SOIC package, ensuring a small footprint on the PCB and making it an excellent choice for space-constrained applications. The package is RoHS compliant and specified over the extended industrial temperature range of -40°C to +125°C, making it robust for industrial environments.

Key features of the ADUM6212CRSZ include:

• Integrated isolated DC-to-DC converter with regulated 5.0 V output
• Up to 150 mW of output power
• High-speed operation with data rates up to 25 Mbps
• High electromagnetic immunity
• 16-lead SOIC package for minimal PCB space usage
• Extended industrial temperature range for high reliability

The product is ideal for a range of applications, including but not limited to, industrial field buses, sensor interfaces, data acquisition systems, and any application where an isolated power supply is required alongside data isolation.

The ADUM6212CRSZ represents Analog Devices' commitment to high-quality and reliable integrated solutions, providing designers with a compact, efficient, and easy-to-implement component for their isolation needs.
