Product Overview

The ADUM3160BRWZ is a robust USB port isolator from Analog Devices Inc., designed to ensure electrical isolation between a USB host and a USB device. This component is part of Analog Devices' iCoupler® family, utilizing proprietary technology to provide 2.5 kV RMS isolation for USB 2.0 data transfer rates up to 12 Mbps. The ADUM3160BRWZ is an essential solution for applications requiring USB isolation to protect against harmful voltage levels and noise, ensuring system stability and integrity.

Key Features

• USB Data Isolation: The device offers 2.5 kV RMS isolation for USB signals, effectively protecting sensitive equipment from surges, spikes, and ground loops.
• Full- and Low-Speed Data Rates: It supports both full-speed (12 Mbps) and low-speed (1.5 Mbps) data rates, making it versatile for a variety of USB applications.
• Automatic Speed Detection: The ADUM3160BRWZ automatically detects and switches between full- and low-speed operation without any manual intervention.
• Bus Powered: This isolator can be powered directly from the USB bus, simplifying design and reducing the need for additional power supplies.
• Compact and Robust Design: Housed in a 16-lead SOIC wide-body package, the ADUM3160BRWZ is designed for space-constrained applications while still providing a robust isolation barrier.

Applications

The ADUM3160BRWZ is ideal for a wide range of applications where USB isolation is critical, including:

• Industrial control systems
• Medical equipment
• Test and measurement devices
• Audio/Video interfaces

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality and reliability, and the ADUM3160BRWZ is no exception. It is designed to meet stringent industry standards, ensuring long-term reliability and performance in demanding environments.

Ordering Information

The product is available in a RoHS-compliant package, with the part number ADUM3160BRWZ. For detailed specifications, application notes, and ordering information, please refer to the official Analog Devices Inc. website or contact an authorized distributor.
