ADM811TARTZ Voltage Supervisor from Analog Devices Inc.

The ADM811TARTZ is a robust voltage supervisor designed by Analog Devices Inc., a leading company in the semiconductor industry. This component is engineered to maintain system integrity by monitoring the power supply voltage in digital systems. It provides a precise, cost-effective solution for applications that require voltage monitoring and power management.

Key Features

• Voltage Monitoring: The ADM811TARTZ keeps a close watch on the supply voltage, ensuring that it remains within the acceptable range for your digital system. It is particularly useful in preventing the corruption of data during power-up, power-down, and brown-out conditions.
• Reset Output: In the event of an undesired voltage fluctuation, this device generates a reset signal. The reset output remains active until the supply voltage stabilizes and meets the specified reset threshold voltage, ensuring proper system restart and initialization.
• Low Power Consumption: Designed with power efficiency in mind, the ADM811TARTZ consumes minimal power, making it an excellent choice for battery-operated devices and power-sensitive applications.
• High Accuracy: This voltage supervisor offers a high level of accuracy in monitoring the supply voltage, which is critical for the reliable operation of sensitive electronic equipment.
• Manual Reset Input: It also features a manual reset input, allowing for an external trigger to initiate a system reset. This is useful for system maintenance or in situations where a manual restart is necessary.

Applications

The ADM811TARTZ is ideal for a wide range of applications, including:

• Microprocessor and microcontroller systems
• Portable and battery-powered equipment
• Industrial controllers
• Automotive systems
• Communication systems
• Data storage and servers

With its compact SOT-143 package, the ADM811TARTZ is suitable for space-constrained applications, and its operating temperature range ensures reliability across various environments. By incorporating the ADM811TARTZ into your system, you can achieve a higher level of protection against voltage anomalies, thus enhancing the overall stability and longevity of your electronic products.
