ADM7170ACPZ-5.0-R7

Part No ADM7170ACPZ-5.0-R7
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Regulators - Linear
Description Adjustable and fixed output voltage options | IC REG LINEAR 5V 500MA 8LFCSP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel
Output Type Fixed
Voltage - Input (Maximum) 6.5V
Min/Fixed Output Voltage 5V
Output Current 500mA
Current - Quiescent (Iq) 2mA
Maximum Supply Current 5.1mA
Control Features Enable, Soft Start
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 8-WFDFN Exposed Pad, CSP
Supplier Device Package 8-LFCSP-WD (3x3)
Family Part Number ADM7170
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 1140950-ADM7170ACPZ-5.0-R7
Manufacturer Homepage www.analog.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ADM7170ACPZ-5.0-R7 CAD Model

Description

ADM7170ACPZ-5.0-R7 - High-Performance LDO Voltage Regulator

The ADM7170ACPZ-5.0-R7 is a state-of-the-art low dropout (LDO) voltage regulator from the renowned manufacturer Analog Devices Inc. This high-precision device is designed to deliver a fixed output voltage of 5.0V with exceptional accuracy and stability, making it an ideal choice for sensitive analog circuits, RF applications, and portable devices that demand a clean and stable power supply.

Encased in a compact, lead-frame chip scale package (LFCSP), specifically the 8-lead CPZ variant, the ADM7170ACPZ-5.0-R7 is not only space-efficient but also boasts excellent thermal performance. Its small footprint is particularly beneficial for space-constrained applications, allowing designers to maintain a slim profile in their electronic designs without compromising on power delivery or thermal management.

One of the key features of this LDO regulator is its low dropout voltage, which enables it to continue regulating the output voltage even when the input-to-output differential is minimal. This characteristic is crucial for battery-powered applications where maximizing the usage of the available input voltage range is essential to prolong battery life.

The ADM7170ACPZ-5.0-R7 is capable of supplying up to 500mA of output current, which is sufficient for a wide range of applications, from powering microcontrollers and FPGAs to providing a clean power source for precision analog-to-digital converters (ADCs) and digital-to-analog converters (DACs). Its high power supply rejection ratio (PSRR) and low noise performance ensure that the output remains free from disturbances present on the input power source.

Additional features of this robust LDO include over-current protection and thermal shutdown, which safeguard the device and the downstream components from damage due to abnormal operating conditions. Moreover, the ADM7170ACPZ-5.0-R7 has a wide input voltage range, supporting applications with varying input voltages while still providing a stable 5.0V output.

In summary, the ADM7170ACPZ-5.0-R7 from Analog Devices Inc. is a superior choice for engineers seeking a high-quality, reliable power management solution. Its combination of low dropout performance, high accuracy, and compact packaging makes it an indispensable component in the design of advanced electronic systems.
