The ADM2582EBRWZ-REEL7 is a fully integrated signal and power isolated data transceiver with ±15 kV ESD protection and is suitable for high-speed communication on balanced transmission lines. Designed and manufactured by Analog Devices Inc., this product is part of their renowned portfolio of interface components that provide robust communication with high levels of signal integrity.

Key Features

• Integrated Isolation: This transceiver integrates Analog Devices Inc.'s iCoupler® technology to provide both signal and power isolation, thereby simplifying design and reducing board space.
• High Data Rates: Capable of supporting data rates up to 16 Mbps, making it ideal for applications requiring high-speed data transfer.
• ESD Protection: Equipped with ±15 kV ESD protection on the transceiver's bus pins, ensuring robustness and reliability in harsh environments.
• Thermal Shutdown Protection: Features a thermal shutdown protection mechanism to prevent damage from overheating.
• Wide Supply Voltage Range: Operates within a supply voltage range of 3.0 V to 5.5 V, accommodating various system voltages.
• Regulatory Approvals: Compliant with industry safety standards, including UL, CSA, and VDE certifications, making it suitable for use in internationally marketed equipment.

Applications

The ADM2582EBRWZ-REEL7 is versatile and can be used in a wide range of applications, including but not limited to:

• Industrial Control Systems
• Building Automation
• Factory Automation
• Networked Sensors and Actuators
• Isolated UART Interfaces

Package and Availability

The device is available in a wide-body, 20-lead SOIC package, ensuring easy integration into existing designs. The "REEL7" designation indicates that this product is provided in a tape and reel format, facilitating efficient handling and placement during the manufacturing process.

Conclusion

With its combination of high-speed data transfer, integrated isolation, and robust protection features, the ADM2582EBRWZ-REEL7 from Analog Devices Inc. represents a superior solution for designers looking to improve communication reliability and protect against electrical noise and transient voltages in their systems.
