Product Overview

The ADG884BCBZ-REEL7 is a high-performance CMOS analog switch manufactured by Analog Devices Inc. This switch is part of the ADG884 series, renowned for its low on-resistance and low on-resistance flatness. The device is packaged in a compact 10-lead MSOP (Micro Small Outline Package) and is provided on a 7" reel, ideal for automated assembly processes used in large-scale manufacturing.

Key Features

• Low On-Resistance: The ADG884 features an exceptionally low on-resistance of less than 0.4 ohms, which remains flat over the full signal range, ensuring minimal signal distortion and power loss.
• Wide Operating Voltage: This switch operates across a broad voltage range from 1.8V to 5.5V, making it versatile for various applications and compatible with many digital interfaces.
• High Current Carrying Capability: With the ability to carry up to 300 mA of continuous current per channel, the ADG884BCBZ-REEL7 is suitable for handling significant power levels.
• Low Power Consumption: The device exhibits ultra-low power dissipation due to its CMOS construction, contributing to energy-efficient designs.
• Dual Single-Pole, Double-Throw (SPDT) Configuration: This configuration allows for flexible routing of analog signals by offering two independent switches in one package.
• ESD Protection: It features robust electrostatic discharge (ESD) protection, ensuring reliability and longevity even in environments prone to ESD events.
• Lead-Free and RoHS Compliant: The product meets environmental standards by being lead-free and compliant with Restriction of Hazardous Substances (RoHS) directives.

Applications

The ADG884BCBZ-REEL7 is ideal for a wide range of applications where high performance and reliability are essential. It is commonly used in:

• Audio and video signal routing
• Data acquisition systems
• Communication systems
• Relay replacements
• Battery-powered systems

With its robust design and versatile features, the ADG884BCBZ-REEL7 from Analog Devices Inc. is an excellent choice for designers looking to implement a reliable switching solution in their electronic systems.
