Product Overview: ADG788BCPZ-REEL7 by Analog Devices Inc.

The ADG788BCPZ-REEL7 is a high-performance, low-voltage, dual 2:1 multiplexer/demultiplexer manufactured by Analog Devices Inc., a leader in high-performance analog, mixed-signal, and digital signal processing integrated circuits. This component is a part of the ADG788 series, which is renowned for its reliability and efficiency in various electronic applications.

Encased in a compact 10-lead LFCSP (Lead Frame Chip Scale Package) with a size of 3mm x 3mm, the ADG788BCPZ-REEL7 is designed for space-constrained applications. It operates over a broad power supply range of ±2.5 V to ±5.5 V or a single supply of 5 V ±10%, making it versatile for both dual and single supply operations.

One of the key features of the ADG788BCPZ-REEL7 is its low on-resistance (typically 4 Ω), which remains flat over the full analog signal range, ensuring excellent linearity and minimal signal distortion. This characteristic, combined with a low on-resistance match between channels and flatness over the signal range, makes this multiplexer ideal for precision signal handling.

The device boasts a fast switching time of t_ON 20 ns and t_OFF 15 ns, which is critical for applications that require rapid signal routing. Additionally, the ADG788BCPZ-REEL7 features a low power consumption, with a typical power supply current of less than 0.1 μA, making it an energy-efficient choice for battery-powered devices.

With its extended temperature range of -40°C to +125°C, the ADG788BCPZ-REEL7 is suitable for use in harsh environments, ensuring reliable performance in industrial and automotive applications. It also has built-in overvoltage protection, which guards the device against momentary voltage spikes, further enhancing its robustness.

The ADG788BCPZ-REEL7 is available in tape and reel packaging, denoted by the suffix 'REEL7', which facilitates efficient assembly processes for high-volume production. Its applications span across data acquisition systems, communication systems, audio and video signal routing, and relay replacement, to name a few.

In summary, the ADG788BCPZ-REEL7 from Analog Devices Inc. is a versatile, high-performance multiplexer/demultiplexer that combines low power operation, fast switching speeds, and robust protection features, making it an excellent choice for a wide range of electronic applications.
