The ADG732BCPZ-REEL by Analog Devices Inc. is a high-performance, 32-channel multiplexer that offers exceptional accuracy and flexibility for a wide range of data acquisition and signal routing applications. This device is part of the REEL packaging series, ensuring efficient handling and manufacturing processes.

Key Features

• Channels: 32 single-ended channels
• Configuration: 1-of-32 multiplexer
• Package: 48-lead LFCSP (7 mm x 7 mm)
• Power Supply: Single 1.8 V to 5.5 V
• Low On Resistance: Typically 2.5 Ω
• On-Resistance Match Between Channels: Typically 0.1 Ω
• On-Resistance Flatness: Typically 0.2 Ω
• Low Total Harmonic Distortion (THD): Excellent signal fidelity
• High Throughput Rate: 3.6 μs typical
• Low Power Consumption: Ideal for battery-powered devices

Applications

The ADG732BCPZ-REEL is suitable for multiple market segments and applications, including:

• Data acquisition systems
• Instrumentation
• Automatic test equipment
• Process control
• Battery-powered systems
• Sample hold systems
• Audio and video switching

Product Description

With its low on-resistance and on-resistance flatness, the ADG732BCPZ-REEL ensures minimal signal distortion and consistent performance across all channels. The device operates on a single 1.8 V to 5.5 V power supply, making it versatile for various power environments. The low power consumption characteristic of the ADG732BCPZ-REEL makes it an excellent choice for portable and battery-operated devices where power efficiency is crucial.

The multiplexer's high throughput rate allows for rapid signal processing, which is essential for high-speed data acquisition and control systems. Additionally, the low total harmonic distortion ensures that the signal integrity is preserved, providing high-fidelity signal routing for audio and video applications.

Engineered for robustness and reliability, the ADG732BCPZ-REEL is delivered in a compact 48-lead LFCSP package, which is suitable for space-constrained applications. Its comprehensive feature set and superior performance make it an ideal solution for engineers looking for a high-quality multiplexer to integrate into their designs.
