Product Overview: ADG714BRUZ from Analog Devices Inc.

The ADG714BRUZ is a high-performance CMOS analog multiplexer from Analog Devices Inc., a leader in high-performance semiconductors. This device is a monolithic, eight-channel multiplexer that offers low on resistance and low capacitance, ensuring minimal signal distortion and fast switching times.

Key Features

• Wide Operating Voltage: The ADG714BRUZ operates from a single 1.8V to 5.5V power supply, making it versatile for various applications that require different voltage levels.
• Low On Resistance: With a typical on resistance of just 4 ohms, this multiplexer provides a high degree of accuracy and minimal signal attenuation.
• Low Power Consumption: The device is designed for low power consumption, which is critical for battery-powered and energy-efficient applications.
• Fast Switching: It offers fast transition times, with t<sub>ON of 150ns and t<sub>OFF of 100ns, ensuring quick response to control signals.
• Break-Before-Make Switching: This feature prevents momentary shorting when switching channels, which is crucial for preventing signal interference and protecting the device.
• Multiple Configurations: The ADG714BRUZ can be configured as an 8:1 multiplexer, dual 4:1 multiplexer, or triple single-pole-double-throw (SPDT) switch, offering flexibility in design.

Applications

The ADG714BRUZ is ideal for a variety of applications, including:

• Data acquisition systems
• Communication systems
• Audio and video switching
• Automatic test equipment
• Relay replacement

Package and Quality

The device is available in a compact 20-lead TSSOP (Thin Shrink Small Outline Package), which is suitable for space-constrained applications. It is also lead-free and RoHS compliant, adhering to environmental standards.

Conclusion

In summary, the ADG714BRUZ from Analog Devices Inc. is a versatile, high-performance analog multiplexer that delivers fast switching, low on resistance, and low power consumption, making it an excellent choice for designers looking for reliable signal routing in their electronic systems.
