Product Overview: ADG713BRUZ-REEL

The ADG713BRUZ-REEL is a high-performance, CMOS analog multiplexer from Analog Devices Inc., a leader in the semiconductor industry. This component is part of their extensive range of switch and multiplexer devices, designed for a variety of signal processing applications.

The ADG713BRUZ-REEL operates with a single supply voltage ranging from 2.7V to 5.5V, which allows for use in both 3V and 5V systems. This flexibility makes it suitable for a wide array of applications, including battery-powered portable devices, where power efficiency is critical.

One of the standout features of this multiplexer is its low on-resistance (typically 4 ohms), which remains flat over the full analog signal range. This characteristic ensures minimal signal distortion and makes the device an excellent choice for precision analog applications. Additionally, the on-resistance profile is very consistent over the entire power supply range, contributing to the device's reliable performance.

The ADG713BRUZ-REEL is a quad SPST (Single Pole Single Throw) switch, meaning it contains four independent switches in a single package. This configuration simplifies design and conserves board space, which is particularly beneficial in compact electronic systems. The switch operation is controlled via a standard TTL/CMOS logic interface, providing ease of use and compatibility with a broad range of control circuitry.

For enhanced durability and long-term reliability, the ADG713BRUZ-REEL features robust ESD (Electrostatic Discharge) protection. It is also fabricated on Analog Devices Inc.'s advanced iCMOS™ (industrial CMOS) process, which combines high-voltage silicon with submicron CMOS and complementary bipolar technologies. This integration results in devices that offer improved performance characteristics compared to traditional CMOS products.

The product is offered in a TSSOP (Thin Shrink Small Outline Package) form factor, under the part number ADG713BRUZ-REEL, and is supplied in tape and reel packaging for efficient handling and manufacturing integration. Whether you are designing for data acquisition systems, communication devices, or medical equipment, the ADG713BRUZ-REEL from Analog Devices Inc. is an excellent choice to ensure high signal integrity and reliable operation.

For detailed specifications and application notes, designers and engineers are encouraged to consult the datasheet and support documentation available from Analog Devices Inc.
