Product Overview: ADG711BRZ by Analog Devices Inc.

The ADG711BRZ is a high-performance CMOS analog switch fabricated by Analog Devices Inc., a leader in the semiconductor industry. This product is designed to provide precision switching on single or dual supply systems. With its low power consumption and wide supply voltage range, the ADG711BRZ is an ideal choice for a multitude of applications including data acquisition systems, sample-hold systems, and audio signal routing.

Key Features

• Single and Dual Supply Operation: The ADG711BRZ operates effectively on a single supply range of 1.8V to 5.5V or a dual supply range of ±2.5V, making it versatile for various circuit configurations.
• Low Power Consumption: With a typical power consumption of less than 0.01µW, it is an energy-efficient solution for battery-powered devices and power-sensitive applications.
• High Switching Speed: The device offers fast switching times (t_ON of 20ns and t_OFF of 10ns), which is suitable for high-frequency signal switching.
• Low On Resistance: Featuring a low on resistance (R_ON) typically around 4Ω, the switch ensures minimal signal distortion and voltage drop.
• Break-Before-Make Switching: This mechanism prevents momentary shorting when switching channels, which is crucial for protecting sensitive circuit components.

Applications

The ADG711BRZ's robust design and electrical characteristics make it suitable for a wide range of applications. It is commonly used in:

• Communication Systems
• Test Equipment and Instrumentation
• Audio and Video Switching
• Relay Replacement
• Portable and Battery-Powered Devices

Package and Quality

The ADG711BRZ comes in a compact 16-lead SOIC (Small Outline Integrated Circuit) package, which is easy to mount on printed circuit boards and is compatible with standard surface mount processes. Analog Devices Inc. ensures the highest quality and reliability of their products, and the ADG711BRZ is no exception, undergoing rigorous testing and quality control measures.
