Analog Devices Inc. ADG711BRUZ-REEL

The ADG711BRUZ-REEL is a high-performance, CMOS analog switch from Analog Devices Inc., designed to deliver precision, reliability, and efficiency for a wide range of applications. This component comes in a compact TSSOP package and is supplied on a 7-inch reel, making it ideal for automated assembly processes, particularly suited for high-volume production environments.

Key Features

• Single Supply Operation: The ADG711BRUZ operates from a single 1.8V to 5.5V supply, providing great flexibility for various circuit designs and ensuring compatibility with low-voltage systems.
• Low On-Resistance: With a typical on-resistance of just 0.5 ohms, this switch ensures minimal signal attenuation and distortion, preserving signal integrity and performance.
• Dual Single-Pole/Double-Throw (SPDT): The device features two independent SPDT switches, which can be used to route signals in complex circuit configurations.
• Fast Switching Times: The ADG711BRUZ boasts fast switching times (t_ON and t_OFF) in the nanosecond range, making it suitable for high-speed signal switching applications.
• Low Power Consumption: This component exhibits low power dissipation, with a typical power consumption of less than 0.01µW, making it an excellent choice for power-sensitive applications.
• High ESD Protection: It offers robust electrostatic discharge (ESD) protection, ensuring durability and longevity in harsh electrical environments.

Applications

The ADG711BRUZ-REEL is versatile and can be utilized in a variety of applications, including:

• Audio and video signal routing
• Data acquisition systems
• Communication systems
• Relay replacements
• Battery-powered systems
• Sample-and-hold circuits

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality, and the ADG711BRUZ-REEL is no exception. Each switch is rigorously tested to meet stringent industry standards, ensuring reliable performance in even the most demanding applications. With its combination of features, the ADG711BRUZ-REEL is a superior choice for designers looking for a switch that offers both precision and durability.
