The ADG5236BRUZ is a robust, high-voltage multiplexer from Analog Devices Inc., designed to deliver exceptional performance in demanding environments. This component is part of a series of monolithic CMOS analog multiplexers/demultiplexers that are latch-up proof, ensuring reliable operation in systems prone to high-voltage spikes. The ADG5236BRUZ is a perfect fit for applications requiring precise signal management, such as data acquisition systems, process controls, and industrial automation.

Key Features

• High-Voltage Tolerance: The device can handle ±22 V for 44 V dual supply, making it suitable for a wide range of applications that require higher voltage levels.
• Enhanced Durability: Latch-up proof technology provides an additional layer of protection against overvoltage, which is crucial for maintaining the integrity of the multiplexer and the safety of the overall system.
• Low On-Resistance: The ADG5236BRUZ features a low on-resistance (Ron) that typically ranges from 10.5 Ω, facilitating efficient signal transmission with minimal signal loss.
• Low Charge Injection: With its low charge injection, this device ensures a cleaner signal path, which is especially beneficial in precision applications.
• Single 8-to-1 Multiplexer Configuration: The ADG5236BRUZ offers a versatile 8-to-1 channel configuration, providing flexibility for various multiplexing needs.

Applications

• Automated Test Equipment (ATE)
• Data Acquisition Systems
• Battery-Powered Systems
• Audio and Video Routing
• Industrial Control Systems

The ADG5236BRUZ is available in a TSSOP package, which is compact and suitable for space-constrained applications. Its operating temperature range of -40°C to +125°C ensures that it can perform reliably in a broad range of environmental conditions. With its combination of high-voltage capability, robust protection features, and low on-resistance, the ADG5236BRUZ from Analog Devices Inc. is an excellent choice for designers seeking a high-performance multiplexer for their next project.
