ADG417BRZ-REEL by Analog Devices Inc.

The ADG417BRZ-REEL is a high-performance, monolithic CMOS analog switch from the esteemed manufacturer Analog Devices Inc., renowned for their precision-engineered electronic components. This particular switch is designed to deliver exceptional accuracy and reliability for a wide range of applications, including data acquisition systems, communication systems, and medical equipment.

Key Features

• Single SPDT Configuration: The ADG417BRZ-REEL features a single pole double throw (SPDT) configuration, which provides versatile switching options between two output ports from a single input.
• Low On-Resistance: With an on-resistance typically in the range of 45 ohms, this switch ensures minimal signal attenuation, making it ideal for precision applications.
• Low Power Consumption: The device operates with a very low power consumption, which is crucial for battery-powered and portable devices.
• Wide Dual Supply Range: It operates with a dual supply voltage ranging from ±4.5 V to ±18 V, or a single supply from 9 V to 36 V, providing flexibility in various power environments.
• Fast Switching Times: The ADG417BRZ-REEL boasts fast transition times with a t_ON of 175 ns and t_OFF of 145 ns, ensuring rapid response in critical applications.
• Enhanced Durability: The device's robust design allows it to withstand continuous operation, contributing to its long service life and reliability.
• Surface-Mount Package: Packaged in a surface-mount SOIC-8 package, it is suitable for automated assembly processes and compact circuit designs.

Applications

The ADG417BRZ-REEL's versatile nature makes it suitable for a variety of applications, including:

• Sample and hold circuits
• Test equipment and instrumentation
• Audio and video signal routing
• Communication systems
• Analog-digital multiplexing

With its high performance and reliability, the ADG417BRZ-REEL from Analog Devices Inc. is an excellent choice for designers and engineers looking for a superior analog switch that can handle critical signals with precision. Its combination of low on-resistance, low power consumption, and fast switching times, packaged in a convenient reel format for ease of manufacturing, makes it a valuable component in any advanced electronic system.
