Product Overview: ADG1604BRUZ from Analog Devices Inc.

The ADG1604BRUZ is a high-performance, monolithic CMOS analog multiplexer from Analog Devices Inc., a leader in high-performance semiconductors. This device features four single-pole/single-throw (SPST) switches, making it an ideal solution for a variety of data acquisition and signal routing applications where low on-resistance, low crosstalk, and high switching speed are paramount.

Key Features

• Low On-Resistance: The ADG1604BRUZ boasts an exceptionally low on-resistance (typically 4.5 ohms), which remains flat over the full signal range, ensuring minimal signal distortion and power loss.
• Single Supply Operation: Designed for single supply operation ranging from +1.8 V to +5.5 V, this versatile multiplexer is suitable for battery-powered and portable devices due to its power efficiency.
• High Switching Speed: With a tON of 30 ns and a tOFF of 20 ns, the ADG1604BRUZ provides rapid switching, beneficial for applications requiring fast signal routing.
• Low Crosstalk and Charge Injection: The device features excellent isolation between channels and minimal charge injection, making it a reliable choice for precision applications.
• Extended Temperature Range: The ADG1604BRUZ operates over an extended industrial temperature range of -40°C to +125°C, catering to a wide array of environmental conditions.

Applications

The ADG1604BRUZ is suitable for multiple applications including, but not limited to:

• Data acquisition systems
• Communication systems
• Audio and video signal routing
• Relay replacement
• Battery-powered systems
• Sample-and-hold systems

Product Specifications

Part Number ADG1604BRUZ Manufacturer Analog Devices Inc. Switch Configuration 4 x SPST On-Resistance (Max) 6 ohms Supply Voltage +1.8 V to +5.5 V Operating Temperature -40°C to +125°C Package/Case TSSOP-14

With its robust design and high-quality performance, the ADG1604BRUZ from Analog Devices Inc. stands out as a top choice for engineers and designers looking for a reliable analog multiplexer.
