Introducing the ADG1406BRUZ Multiplexer by Analog Devices Inc.

Unlock the full potential of your electronic designs with the ADG1406BRUZ, a high-performance 16-channel multiplexer brought to you by Analog Devices Inc., a leader in precision engineering. This versatile component is an integral part of the ADG1406 series, renowned for its reliability and cutting-edge technology.

The ADG1406BRUZ is designed to operate with a dual supply range of ±4.5 V to ±18 V or a single supply range of 9 V to 36 V, making it incredibly versatile for various applications. Its robust design ensures that it can easily handle continuous current up to ±20 mA. With its on-resistance profile being typically flat over the full analog input range, this multiplexer ensures excellent linearity and low distortion, which is crucial for precision analog applications.

Featuring an extended industrial temperature range of -40°C to +85°C, the ADG1406BRUZ remains reliable in even the most demanding environments. Its TSSOP (Thin Shrink Small Outline Package) encapsulation provides a compact footprint, saving valuable board space while maintaining high performance.

Key features of the ADG1406BRUZ include:

• 16:1 channel configuration
• Low on-resistance (< 4.5 Ω typical)
• Low on-resistance flatness
• Break-before-make switching action
• Single 8-channel or dual 4-channel operation
• 3 V logic-compatible inputs
• Ultralow power dissipation
• ESD protection > 2 kV

This multiplexer is perfect for data acquisition systems, process controls, and instrumentation applications where a high density of analog signals needs to be managed without compromising signal integrity. Whether you're designing for industrial, communication, or healthcare systems, the ADG1406BRUZ provides the reliability and performance you need.

With the ADG1406BRUZ, Analog Devices Inc. offers a solution that combines efficiency with precision, ensuring that your products are equipped with the finest components in the market. For further details and specifications, consult the datasheet and support documentation available on the Analog Devices website or contact your local distributor.

Choose the ADG1406BRUZ for your next project and experience the difference in quality and performance that Analog Devices Inc. consistently delivers.
