Product Overview: ADG1404YRUZ-REEL7 by Analog Devices Inc.

The ADG1404YRUZ-REEL7 is a high-performance, monolithic CMOS analog multiplexer from Analog Devices Inc., a renowned leader in the semiconductor industry. This product is part of their comprehensive portfolio of switch and multiplexer devices, designed to provide efficient solutions for routing analog signals in a wide array of applications.

Encased in a compact TSSOP-14 package, the ADG1404YRUZ-REEL7 offers four single-pole/single-throw (SPST) switches, which are ideal for applications that require a high degree of precision and reliability. The device operates on a single 3 V to 16 V power supply or a dual ±3 V to ±8 V power supply, providing versatility in various circuit configurations.

One of the key features of this analog multiplexer is its low on resistance, typically just 4 ohms, which ensures minimal signal distortion and preserves the integrity of the analog signal being switched. Furthermore, the on resistance is closely matched between switches and remains flat over the full analog signal range, contributing to excellent overall performance.

The ADG1404YRUZ-REEL7 also boasts a low total harmonic distortion (THD) and a wide bandwidth, making it suitable for audio and video signal routing, as well as for other high-frequency applications. Its robust design ensures that it can handle continuous current up to 120 mA per channel, and it features fast switching times that enhance the responsiveness of the system it is integrated into.

This device is available in a tape and reel format (REEL7), which facilitates automated assembly processes, making it a convenient choice for mass production environments. It is also characterized by its extended industrial temperature range, ensuring reliable operation even under harsh conditions.

In summary, the ADG1404YRUZ-REEL7 from Analog Devices Inc. is a high-quality, versatile analog multiplexer that offers exceptional performance for a variety of applications. Its low on resistance, matched channel-to-channel characteristics, and fast switching capabilities make it a preferred choice for design engineers looking for efficient signal routing solutions.
