Introducing the ADG1204YRUZ from Analog Devices Inc.

The ADG1204YRUZ is a high-performance, monolithic CMOS device comprising four independently selectable single-pole, double-throw (SPDT) switches. It's an ideal choice for a wide range of applications, including data acquisition systems, communication systems, and relay replacement, thanks to its low on-resistance, low crosstalk, and high signal integrity.

Key Features

• Low On-Resistance: The ADG1204YRUZ boasts an ultra-low on-resistance of typically just 1.5 ohms, which is consistent over the full signal range. This feature ensures minimal signal distortion and power loss, making it perfect for precision signal routing.
• Wide Operating Voltage Range: With an operating voltage range of ±5 V to ±16.5 V or a single 10 V to 33 V supply, this switch can easily fit into a variety of system designs without requiring additional power supply rails.
• High ESD Protection: Electrostatic discharge protection is built-in, withstanding up to 2 kV Human Body Model, ensuring robustness and reliability in harsh electrical environments.
• Break-Before-Make Switching: This feature guarantees that when switching between two channels, the connection with the first channel is broken before the connection with the second channel is made, preventing any chance of shorting the two channels.

Applications

The ADG1204YRUZ is versatile and can be used in various applications, including:

• Automatic Test Equipment
• Data Acquisition Systems
• Communication Systems
• Sample Hold Systems
• Battery Powered Systems

Package and Quality

Enclosed in a compact 14-lead TSSOP (Thin Shrink Small Outline Package), the ADG1204YRUZ is designed for space-saving on PCBs while offering excellent thermal performance. Analog Devices Inc. ensures the highest quality, with each device rigorously tested and certified to meet stringent industry standards.

For designers looking for a reliable, high-performance switching solution, the ADG1204YRUZ from Analog Devices Inc. offers a perfect blend of features that enhance system performance while maintaining simplicity and efficiency in design.
