The ADF4360-0BCPZ is a high-performance, integrated synthesizer from Analog Devices Inc. that offers a complete solution for generating a wide range of frequencies for various applications. This device is part of the ADF4360 family, which is known for its reliability and versatility in frequency generation.

Key Features

• Integrated VCO: The ADF4360-0BCPZ features an integrated voltage-controlled oscillator (VCO) with a frequency range of 2400 MHz to 2725 MHz, providing a stable and precise output signal.
• Programmable Divider: It includes a fully programmable dual-modulus prescaler, as well as programmable charge pump currents and phase detector polarity, allowing for flexible frequency configuration.
• Low Noise: The synthesizer is designed with low phase noise performance, making it suitable for applications that require a clean signal source.
• Power Supply: The device operates on a 3.0 V to 3.6 V power supply, ensuring compatibility with a wide range of systems and applications.
• Compact Package: Enclosed in a 20-lead LFCSP (lead-frame chip-scale package), the ADF4360-0BCPZ is designed for space-constrained applications without compromising functionality.

Applications

The ADF4360-0BCPZ is ideal for a variety of applications, including:

• Wireless infrastructure (GSM, WCDMA, LTE)
• Test equipment
• Clock generation
• Wireless LANs
• Personal communication systems

Technical Specifications

With its comprehensive feature set and robust design, the ADF4360-0BCPZ from Analog Devices Inc. is a superior choice for professionals looking for a reliable frequency synthesizer that can meet a broad range of requirements.
