ADAU1450WBCPZ

Part No ADAU1450WBCPZ
Manufacturer Analog Devices Inc.
Catalog Embedded - DSP (Digital Signal Processors)
Description SigmaDSP Digital Audio Processor | IC AUDIO PROCESSOR 72LFCSP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Tray
Type Sigma
Interface I2C, SPI
Clock Rate 147.456MHz
Non-Volatile Memory ROM (32 kB)
On-Chip RAM 32kB
Voltage - I/O 3.30V
Voltage - Core 1.20V
Temperature Range - Operating -40°C ~ 105°C
Mounting Style SMD
Manufacturer Package 72-VFQFN Exposed Pad, CSP
Supplier Device Package 72-LFCSP-VQ
Family Part Number ADAU1450
Manufacturer Pack Quantity 168
MSL Level 3 (168 Hours)
Win Source Part Number 1139536-ADAU1450WBCPZ
Manufacturer Homepage www.analog.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ADAU1450WBCPZ CAD Model

Description

The ADAU1450WBCPZ is a sophisticated audio digital signal processor (DSP) from Analog Devices Inc., designed to cater to the needs of advanced audio processing applications. This high-performance SigmaDSP® core is an ideal solution for automotive audio systems, home theater systems, and professional audio equipment, offering a flexible and programmable platform for audio signal processing.

Key Features

  • High-Performance Signal Processing: The ADAU1450WBCPZ boasts a 32-bit SigmaDSP core with 294.912 MHz core speed, providing ample processing power for complex audio algorithms and signal processing tasks.
  • Memory: This DSP is equipped with 1.2Mbits of on-chip RAM, allowing for extensive audio processing without the need for external memory components.
  • Audio Input/Output: It supports a variety of audio input and output configurations, making it highly adaptable to different system architectures.
  • Low Power Consumption: Designed with power efficiency in mind, the ADAU1450WBCPZ ensures minimal power consumption, which is crucial for battery-operated devices and automotive applications.
  • Flexibility: The device can be programmed via Analog Devices' SigmaStudio software, which offers a user-friendly graphical programming environment.

Applications

  • Automotive audio systems
  • Home theater and entertainment systems
  • Professional audio equipment
  • Active speakers and soundbars

Technical Specifications

Parameter Value
Core Processor SigmaDSP
Core Speed 294.912 MHz
On-chip RAM 1.2Mbits
Operating Temperature -40°C to +105°C
Package / Case 64-LFCSP (9x9)

The ADAU1450WBCPZ from Analog Devices Inc. is a powerful and versatile audio DSP that is well-suited for a wide range of applications requiring high-quality audio processing. Its combination of performance, flexibility, and efficiency makes it an excellent choice for designers and engineers looking to push the boundaries of audio technology.
