AD8302ARU-REEL7

Part No AD8302ARU-REEL7
Manufacturer Analog Devices Inc.
Catalog RF Detectors
Description LF.2.7 GHz RF/IF Gain and Phase Detector | IC RF DETECT 2.7GHZ 14TSSOP
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Analog Devices Inc.
Packaging Tape and Reel
Status Obsolete
Frequency 2.7GHz
RF Type General Purpose
Input Range -60dBm ~ 0dBm
Accuracy ±0.5dB
Supply Voltage (V) 2.7V ~ 5.5V
Supply Current 23mA
Manufacturer Package 14-TSSOP
Supplier Device Package 14-TSSOP
Family Part Number AD8302
Manufacturer Pack Quantity 1,000
MSL Level 1 (Unlimited)
Win Source Part Number 1138434-AD8302ARU-REEL7
Manufacturer Homepage www.analog.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AD8302ARU-REEL7 CAD Model

Description

The AD8302ARU-REEL7 is a fully integrated system from Analog Devices Inc. designed for measuring amplitude and phase between two independent input signals. This highly sophisticated IC is specifically engineered to provide precise and reliable measurements in a variety of applications, including RF/IF signal monitoring, antenna alignment, phase detection, and network analysis.

Key Features:

  • Wide Bandwidth: The device is capable of operating over a wide frequency range, making it suitable for a broad spectrum of RF and IF applications.
  • Dual Demodulating Log Amps: It features two closely matched demodulating logarithmic amplifiers that provide a measurement range of 60 dB.
  • Phase Measurement Range: The AD8302ARU-REEL7 offers an excellent phase measurement range of 0 to 180 degrees.
  • High Accuracy: With its precision design, this component delivers highly accurate amplitude and phase measurements.
  • Single Supply Operation: It operates from a single 2.7 V to 5.5 V supply, simplifying the power supply design.
  • Compact Package: Housed in a TSSOP-14 package, the AD8302ARU-REEL7 is compact and suitable for space-constrained applications.

Applications:

  • Wireless base station signal monitoring
  • Data converter calibration
  • Antenna beam forming
  • RF instrumentation and radar systems
  • Communication system diagnostics

The AD8302ARU-REEL7 is provided in a reel format, facilitating its integration into automated manufacturing processes, enhancing production efficiency and consistency. With its robust design and advanced functionality, the AD8302ARU-REEL7 from Analog Devices Inc. is a versatile and valuable component for engineers working on sophisticated electronic systems where precise signal measurement is paramount.
