Product Overview: AD7928WBRUZ-REEL

The AD7928WBRUZ-REEL is a high-performance, 8-channel, 12-bit analog-to-digital converter (ADC) from Analog Devices Inc., a leading name in precision high-performance integrated circuits. This ADC is part of a series of devices that feature a 12-bit ADC with a fast track-and-hold and a high-speed serial interface. Designed to operate from a single 2.7 V to 5.25 V power supply, the AD7928 is optimized for dynamic performance and low power in applications where a small package size is critical.

Key Features

• Resolution: The AD7928 boasts a 12-bit resolution, offering fine granularity for precise data conversion from analog signals to digital form.
• Multiple Input Channels: With 8 single-ended input channels, this device provides flexibility for multiplexed data acquisition systems, allowing for multiple sensor readings with a single ADC.
• Sampling Rate: It features a fast conversion rate of up to 1 MSPS (million samples per second), ensuring timely data capture for real-time applications.
• Interface: The device includes a high-speed SPI-compatible serial interface, facilitating easy integration with a wide range of microcontrollers and digital systems.
• Power Supply: The ADC operates on a single 2.7 V to 5.25 V power supply, accommodating various power environments and contributing to system power efficiency.
• Low Power Consumption: It is designed for low power operation, which is ideal for battery-powered devices and power-sensitive applications.
• Package: The AD7928 is available in a compact 20-lead TSSOP (Thin Shrink Small Outline Package), making it suitable for space-constrained applications.
• Temperature Range: The device is specified for operation over the extended industrial temperature range of −40°C to +85°C, ensuring reliability in harsh environments.

Applications

The AD7928WBRUZ-REEL is suitable for a wide array of applications, including:

• Data acquisition systems
• Battery-powered instruments
• Medical instruments
• Industrial control systems
• Communication systems

With its robust feature set, the AD7928WBRUZ-REEL from Analog Devices Inc. stands out as a versatile and efficient solution for precise data conversion in both commercial and industrial applications.
